Application
Use for two profiles right angle connection.Insert both ends separately to slot when installed, Lock fastening screws, Please choose different interior bracket according the profiles slot and connect method.
Product Description
| L | L1 | L2 | W | W1 | H | Mx | |
| 30 series | 14.8 | 7.7 | 7.5 | 37.2 | 25.2 | 31.4 | M6 |
| 40 series | 19 | 8 | 8.7 | 37.5 | 24.4 | 31.4 | M6 |
| 45 series | 19 | 10 | 8 | 37.8 | 24.4 | 31.5 | M8 |
